Compatible lenses & ports list
Compatible cameras:
Compatible lenses (6" Glass dry dome port V.10)
- Sony FE 16-35mm F/2.8 GM II (Autofocus only, Manual zoom gear - purchase here)
- Sony FE 16-35mm F4 ZA OSS (Autofocus only, Manual zoom gear included)
- Sony FE 12-24mm F4 G (Autofocus only, Manual zoom gear available -purchase here)
- Sony FE 24mm F1.4 GM (Autofocus only)
- Sony FE 24-70mm F4 ZA OSS (Autofocus only, correct work from 24 to 50mm, Manual zoom gear - purchase here)
- Sony FE 28mm F2 + Ultra Wide Converter SEL075UWC (Autofocus only)
- Sony FE 28-70mm F3.5-5.6 OSS (Autofocus only, Manual zoom gear not included)
- Sony FE 35mm F1.4 ZA (Autofocus only)
- Sony FE 55mm F1.8 ZA (Autofocus only)
- Tamron 17-28mm F2.8 Di III RXD (Autofocus only, Manual zoom gear - purchase here)
- Sigma 14-24mm F2.8 DG DN Art (Autofocus only, No manual zoom gear)
- Sigma 35mm F1.4 e mount (Manual focus, available - purchase here)
Key Features:
- Key Features:
- Inbuilt leak sensor
- Depth rate 40m/130ft
- Dual Fiber-Optic port (Sea&Sea type)
- Optical flash trigger (Optional)
- Port for vacuum test system
- Stainless steel mounting plate 1/4" Thread
- Interchangeable port system
- High-quality optical viewfinder
- Double-sided metal hinge lock
- Zoom control for FE 16-35mm F4 ZA OSS
In order to connect an external strobe with this housing, it will require to use of a Fiber-optic cable (purchase here)
Dimensions:
- Width: 20cm
- Height: 20cm
- Length: 22cm
- Weight: ±1356 GR (2.9 LBS)
- Buoyancy: Positive
Accessible Controls:
- All functions available
- Shutter button
- ON/OFF
- Mode selector dial
- Control dial
- Flash button
- MENU button
- AF/MF - AEL
- Enlarge button
- Video record button
- FN button
- Control wheel
- Center button
- C1 button
- C2 button
- C3/delete button
- Playback button
Materials :
- Polycarbonate
- ABS plastic
- Optical acryl
- Stainless steel
- EPDM rubber
- O'ring sealed buttons with spring
Package Includes:
- Underwater housing
- 6" Glass Dry Dome Port V.10
- Zoom gear for FE 16-35mm F4 ZA OSS lens
-
Spare O-rings set
-
Housing body cap
-
Port cap (back)
-
Neoprene cover
-
Shoulder & wrist strap
-
Silicone grease (5ml)
-
User manual
